Robotics Question & Answers July 26, 2022 By WatElectronics This article lists 100 Robotics MCQs for Engineering Students. The Robotics Questions & Answers below include solutions and links to the relevant topic. This is helpful for users who are preparing for their exams and interviews, or professionals who would like to brush up on the fundamentals of Robotics. The robots are classified based on configuration, depending on the control system, and generation. The first-generation robots are remote-controlled, second-generation robots are autonomous example cleaning bots, and the third-generation robots are comes under network technology whereas the teleoperated and autonomous are two subclasses of networked robots, and the fourth-generation robots are starship delivery robots, nimbo security robots, etc come under artificial intelligence robots. The cartesian robots are commonly used for assembly operations, arc welding, and handling machine tools. The advantages of cartesian robots are easy computation & programming, and the most rigid structure for a given length the disadvantages are they require large operating volume, and axes are hard to seal. The cylindrical robots are commonly used for handling die casting machines, assembly operations, and spot welding. The articulated robots are commonly used for welding, spray painting, weld sealing, assembly operations, etc. The advantages of articulated robots are all rotary joints allow for maximum flexibility, any point in total volume can be reached, and all joints can be sealed from the environment. The disadvantages are they are extremely difficult to visualize, control, and program, and have low accuracy. Name Email 1). The robots with the designation TRI are known as ___________ robots? Spherical Articulated Both a and b None of the above Hint 2). How many sections does robot manipulator consists of? One Two Three Four Hint 3). Which one of the following generation robots are remote controlled? First Second Third None of the above Hint 4). What is the standard form of DOF? Degree of Finance Degree of Freedom Degree of Fail None of the above Hint 5). The study of motion without regard to forces is known as _________? Kinematics Dynamics Actuator Sensor Hint 6). Which one of the following robots also called spherical robot? SCARA Delta Polar None of the above Hint 7). Which one of the following robots comes under first generation? Information robots Autonomous loading Autonomous harvesting None of the above Hint 8). Which one of the following engineering deals with machinery and structure of robots? Electrical Mechanical Computer All of the above Hint 9). ____________ is an example for simple level robots? Washing machine Fully automatic washing machine Laptop None of the above Hint 10). The robots with the designation TRR is known as ____________ robots? Spherical Articulated Both a and b None of the above Hint 11). The dynamic robots are categorized into _____________ types? One Two Three Four Hint 12). What is the standard form of ZMP? Zero Memory Point Zero Momentum Point Zero Main Point None of the above Hint 13). The joints of the robots are categorized into _________ types? One Two Three None of the above Hint 14). Which one of the following sections in robot manipulator used for positioning? Body & arm Wrist assembly Both a and b None of the above Hint 15). The study of motion with regard to forces is known as _________________? Kinematics Dynamics Actuator All of the above Hint 16). How many categories of sensors are used in industrial robots? One Two Three Four Hint 17). What is the standard form of FCAW? Flux Common Arc Welding Flux Cored Arc Welding First Cored Arc Welding None of the above Hint 18). What are the advantages of robots? Don't need experience Cost lot of money Need a huge power supply Replace human workers Hint 19). The robots are categorized into _______________ types based on control system? One Two Three None of the above Hint 20). Which one of the following joints comes under translational motion? Orthogonal Joint Rotational Joint Twisting Joint None of the above Hint 21). Which one of the following robots is based on physical configuration? SCARA Point to point Controlled path Continuous path Hint 22). Which one of the following robots with two prismatic joints? Cartesian Cylindrical Articulated None of the above Hint 23). What are the advantages of SCARA? Limited applications Two ways to reach point Highly complex High speed Hint 24). Which one of the following commonly used for weld sealing? Cartesian Articulated Cylindrical None of the above Hint 25). What are the advantages of articulated robots? All joints can be sealed from the environment Low accuracy Restricted volume coverage Extremely difficult to visualize Hint Robotics MCQs for Quiz 26). What is the standard form of LRC? Locked Room Code Locked Rotor Code Last Rotor Code None of the above Hint 27). Which one of the following is flexible and easy to use? Robot Cobot Both a and b None of the above Hint 28). In which one of the following, minimum integrations is required? Robot Cobot Both a and b None of the above Hint 29). Which one of the following robots commonly used for handling at die casting machine? Cylindrical Cartesian Both a and b None of the above Hint 30). How many types of robotic joints are there? Five Two Three None of the above Hint 31). Which one of the following sections in robot manipulator used for orientation of objects? Body & arm Wrist assembly Both a and b None of the above Hint 32). Which one of the following generation robots are autonomous? First Second Third None of the above Hint 33). Which one of the following robots comes under second generation? Information robots Autonomous loading Water Inspection None of the above Hint 34). ________________ is an example for middle level robots? Washing machine Fully automatic washing machine Laptop None of the above Hint 35). What is the standard form of PTP? Point to Point Point to Path Path to Point None of the above Hint 36). Which one of the following joints comes under rotary motion? Orthogonal Joint Linear Joint Both a and b Revolving Joint Hint 37). Which one of the following robots is based on control system? SCARA Polar Cylindrical Continuous path Hint 38). The robots are categorized into _________________ types based on physical configuration? One Two Four Five Hint 39). Which one of the following robots with three prismatic joints? Cartesian Cylindrical Articulated None of the above Hint 40). Which one of the following generation robots are networked? First Second Third Fourth Hint 41). Which one of the following provides force for robot motion? Kinematics Dynamics Actuator None of the above Hint 42). Which one of the following engineering deals with controlling and intelligence of robots? Electrical Mechanical Computer None of the above Hint 43). Which one of the following robots with at least three rotary joints? Cartesian Cylindrical Articulated None of the above Hint 44). What are the disadvantages of SCARA? Limited applications Height axis is rigid Large work area None of the above Hint 45). What are the disadvantages of articulated robots? All joints can be sealed from the environment Low accuracy Restricted volume coverage Both b and c Hint 46). Which one of the following have high precision and repeatability? Robot Cobot Both a and b None of the above Hint 47). Which one of the following robots commonly used for pick and place work? Cylindrical Cartesian Both a and b None of the above Hint 48). What are the benefits of delta robots? Very high speed Light weight Good repeatability All of the above Hint 49). What are the benefits of SCARA robots? High speed High repeatability Limited payloads Both a and b Hint 50). Which one of the following generation robots are artificial intelligence? First Second Third Fourth Hint Read more about Artificial Intelligence Robotics MCQs for Exams 51). Which one of the following reads variables in robot motion for use in control? Kinematics Dynamics Actuator Sensor Hint 52). Which one of the following engineering deals with the movement, development, and observation of robots? Electrical Mechanical Computer None of the above Hint 53). _________________ is an example for complex level robots? Washing machine Fully automatic washing machine Laptop None of the above Hint 54). Which one of the following is safer? Cobot Robot Both a and b None of the above Hint 55). In which one of the following robots, the programming is time consuming? Collaborative robots Conventional industry robots Both a and b None of the above Hint 56). The weight of collaborative robots is less than ________________ kgs? <29 <78 <54 None of the above Hint 57). What are the main components of robots? Control system Sensors Both a and b None of the above Hint 58). How many types of prosthetic limbs are there? One Two Three Four Hint 59). What is the standard form of MPL? Modular Parallel Limb Modular Plane Limb Modular Prosthetic Limb None of the above Hint 60). Which one of the following level robots are never be reprogrammed? Simple level Middle level Complex level None of the above Hint 61). What are the disadvantages of robots? Don't need experience Cost lot of money Don't get bored Works in dangerous environment Hint 62). The figure shown below is a block diagram of _______________ system? Robotic Control Surgical robotics None of the above Hint 63). Which one of the following is susceptible to radiation and infection? Human Robots Both a and b None of the above Hint 64). What are the benefits of articulated robots? High loads/very flexible Large foot prints Lower speed, high cost All of the above Hint 65). What are the benefits of cartesian robots? Large work envelope Large foot print Lower speed Both a and b Hint 66). Which one of the following intelligences is created by human intelligence? Artificial intelligence Human intelligence Both a and b None of the above Hint 67). In which one of the following intelligence, the process information is slower? Artificial intelligence Human intelligence Both a and b None of the above Hint 68). Which one of the following intelligences cannot be adapt to changes well? Artificial intelligence Human intelligence Both a and b None of the above Hint 69). What are the advantages of cartesian robots? Easy computation and programming Axes hard to seal Can only reach front of itself Requires large operating volume Hint 70). Which one of the following level robots are reprogrammed? Simple level Middle level Complex level None of the above Hint 71). Which one of the following robots with at least two parallel rotary joints? Cartesian Cylindrical Articulated SCARA Hint 72). In which one of the following, the process information is faster? Artificial intelligence Human intelligence Both a and b None of the above Hint 73). Which one of the following intelligences uses brain power? Artificial intelligence Human intelligence Both a and b None of the above Hint 74). Which one of the following intelligences uses two watts? Artificial intelligence Human intelligence Both a and b None of the above Hint 75). Which one of the following made of metal and other non-organic material? Humanoid robot Android Both a and b None of the above Hint Robotics MCQs for Students 76). What is standard form of LISP? Low Level Simple Program Low Level Small Program List Processing None of the above Hint 77). What is standard form of VAL II? Variable Language Variable Assembly Language Variable Assembly List None of the above Hint 78). Which one of the following robots is used to perform household tasks? Domestic robots Educational robots Both a and b None of the above Hint 79). Which one of the following is unsusceptible to radiation and infection? Human Robots Both a and b None of the above Hint 80). Which one of the following robots with one prismatic joint? Cartesian Cylindrical Articulated Spherical/polar Hint 81). What are the advantages of cylindrical robots? Linear axes is hard to seal Wont reach around obstacles Can reach all around itself Can't reach above itself Hint 82). Which one of the following is potentially danger for human safety? Cobot Robot Both a and b None of the above Hint 83). In which one of the following robots, the programming is simple? Collaborative robots Conventional industry robots Both a and b None of the above Hint 84). Which one of the following robots is not less in weight? Collaborative robots Conventional industry robots Both a and b None of the above Hint 85). Which one of the following intelligences can beat the spped of computers? Artificial intelligence Human intelligence Both a and b None of the above Hint 86). The figure shown below is a block diagram of _______________ system? Robotic arm Control Surgical robotics None of the above Hint 87). Which one of the following is an example for autonomous robot? Hospitability bots Medical assistant bots Both a and b None of the above Hint 88). The maximum climbing speed of wall climbing robot is __________________ inch/sec? 15 inch/sec 9 inch/sec 25 inch/sec 40 inch/sec Hint 89). How many ways are there to represent the robot location? Add description here! One Two Three Four Hint 90). What are the disadvantages of cylindrical robots? Linear axes is hard to seal Won't reach around obstacles Can reach all around itself Both a and b Hint 91). What is the standard form of BLDC? Brushless Direct Current Motor Brushless Distinct Current Motor Brushless Direct Common Motor None of the above Hint 92). Which one of the following robots for educational purpose? Domestic robots Educational robots Both a and b None of the above Hint 93). The robots move the __________________ from one to another place in the material handling application? Materials Parts Materials or parts None of the above Hint 94). How many processes does machine loading and unloading includes? One Two Three None of the above Hint 95). Which one of the following robots is easy to move? Collaborative robot Traditional industry robot Both a and b None of the above Hint 96). What is the standard form of SFA? Service First Amps Service Factor Amps Simple Factor Amps None of the above Hint 97). Which one of the following robots is difficult to move? Collaborative robot Traditional industry robot Both a and b None of the above Hint 98). What are the advantages of robots? Saving companies' time Increased profitability Higher quality All of the above Hint 99). What is standard form of SCARA? Selective Compliance Articulated Robot Arm Simple Compliance Articulated Robot Single Compliance Articulated Robot None of the above Hint 100). How many modes of operations are there? One Two Three None of the above Hint Please fill in the comment box below. Time is Up! Time's up
